HYBRID INVERTER (OFF-GRID)

Single Phase: GF1-8KS2M/12KS2

The GF1 8-12KS2 series is an off-grid solar inverter combining economy and high performance, designed for backup power, off-grid, providing uninterruptible power support and ESS applications. This inverter uniquely integrates generator interface, AC coupling and smart load output interface for true versatility. The intuitive operator interface and intelligent monitoring features also make energy management easy and simple.In addition, it can handle high surge loads, and the extremely short on/off switching time ensures that critical loads continue to operate during power outages, increasing the stability and high reliability of system operation.

Datasheet
Dual MPPT design, compatible with 182/210 solar modules
Color LCD touchscreen with integrated LED light for intelligent status display
Flexible expansion, independent ports for generator & smart load connection
250A/250A max charge/discharge current for fast power backup
Sleek industrial design, easy to install and operate
HYBRID (Off-Grid) INVERTER
GF1-8KS2M
Max. PV Input Power
16000 W
Max. PV Input Voltage
500 V
Max. PV Input Current
32/32 A
Max. AC Input Power
13800 W
Max. Efficiency
97.60%
Protection Rating
IP66
Battery Type
Li-ion
Dimension (W*H*D)
496*505*225 mm
HYBRID (Off-Grid) INVERTER
GF1-12KS2
Max. PV Input Power
24000 W
MPPT Voltage Range
60~500 V
Max. PV Input Current
32/32/32 A
Max. AC Input Power
13800 W
Max. Efficiency
97.60%
Protection Rating
IP66
Battery Type
Li-ion
Dimension (W*H*D)
496*505*225 mm
