Wi-Fi Dongle PSD300.R110 USB Connection Pluggable Support IP65

PSD300.R110

The PSD300.R110 inverter data acquisition terminal product supports USB physical connector, supports WiFi/Ethernet communication method in the uplink, and supports RS485 communication in the downlink. It can realize data collection and data transmission of the inverter, collect and record the working status and power generation status of the inverter, and easily support the access operation and maintenance of the power station. Application scenarios: It is widely used in household industrial and commercial power stations to collect and record the working status and power generation status of the inverter, and remotely monitor the photovoltaic power generation system through a professional platform to help users manage distributed power stations with low cost and high efficiency.

Easy to install, plug and play, convenient and fast

Support local/remote upgrade, support breakpoint resumption

Supports 7-day offline data caching

Password protection, encrypted transmission, and protection of user data security

Support IP65

Wi-Fi Dongle

PSD300.R110


Supported Device Types	Livoltek Inverters
Number of Supported Devices	1
Data Collection Interval	5 minutes/times
Status Display	LED x 3
Communication Interface	RS485
Communication Port	RS485 communication port, Modbus-RTU Protocol Baud rate:1200、2400、4800、9600、19200、38400、115200(configurable)
Ethernet Communication	Number of ways *1, 10/100MbpsAdaptive, Communication distance≤100m
WLAN Communication	2.4GHz/ 802.11 b/g/n，support STA/AP/STA+AP model
Input Voltage	DC 5V
Operating Power Consumption	≤5W
Operating Temperature	-30 ~ +65° C
Working Humidity	5% – 95%，Relative humidity non-condensing
Storage Temperature	-40 ~ +70° C
Working Altitude	≤ 3000m
Protection Level	IP65
Dimensions (lengthwidthheight )	31.5mm x 43.3mm x 158.5mm
Installation Method	pluggable
